双 真空 包装 设备 500-700mm
SKU: HB-106
| Parameter | DZ-500/2SA3 (Flatbed) | DZ-500/2SB3 (Grooved) | DZ-600/2SA3 (Flatbed) | DZ-600/2SB3 (Grooved) | DZ-700/2SA3 | DZ-820/2SA (Brushed 201 Steel) | DZ-820/2SA (Manual, Sandblasted 304 Steel) | DZ-820/2SA (Full-Automatic, Sandblasted 304 Steel) | DZ-820/2SA (Extended Width, Sandblasted 304 Steel) |
|---|---|---|---|---|---|---|---|---|---|
| Basic Information | |||||||||
| English Name | Double Chamber Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine | Full-Automatic Vacuum Packaging Machine | Double Chamber Vacuum Packaging Machine |
| Model | DZ-500/2SA3 | DZ-500/2SB3 | DZ-600/2SA3 | DZ-600/2SB3 | DZ-700/2SA3 | DZ-820/2SA | DZ-820/2SA | DZ-820/2SA | DZ-820/2SA |
| Lid Design | Tower Lid | Tower Lid | Tower Lid | Tower Lid | Tower Lid | Tower Lid | Tower Lid | Tower Lid | Tower Lid |
| Technical Specifications | |||||||||
| Power Supply (V/Hz) | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 |
| Vacuum Pump Motor Power (W) | 2000 | 2000 | 2000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| Sealing Power (W) | 800 | 800 | 1000 | 1300 | 1500 | 1400 | 1400 | 1400 | 1400 |
| Ultimate Vacuum Pressure (KPa) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Number of Sealing Bars per Chamber | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Chamber Dimensions (L×W×H) (mm) | 570×520×100 | 550×428×120 | 670×570×120 | 660×550×180 | - | 880×755×170 | 880×755×170 | 880×755×170 | - |
| Chamber Effective Dimensions (L×W×H) (mm) | - | - | - | - | 700×500×180 | - | - | - | 800×770×170 |
| Sealing Length (mm) | 520 | 500 | 600 | 600 | 700 | 820 | 820 | 820 | 820 |
| Sealing Width (mm) | 10 | 10 | 10 | 10 | 10 | 8 | 8 | 8 | 8 |
| Vacuum Pump Rate (m³/h) | 20×2 | 20×2 | 20×2 | 20×3 | 20/40/63/100 | 100 | 100 | 100 | 200 |
| Chamber Material | Stainless Steel 201 | Stainless Steel 304 | Stainless Steel 201 | Stainless Steel 304 | Stainless Steel 201 | Stainless Steel 201 (Brushed) | Stainless Steel 304 (Sandblasted) | Stainless Steel 304 (Sandblasted) | Stainless Steel 304 (Sandblasted) |
| External Dimensions (L×W×H) (mm) | 1225×692×924 | 1205×632×950 | 1425×632×932 | 1405×712×959 | 1700×670×1010 | 2050×868×1020 | 2050×868×1020 | 2050×868×1020 | 2050×1100×1020 |
| Net Weight (kg) | 162 | 178 | 188 | 305 | 265 | 295 | 295 | 295 | 295 |
| Center Distance Between Sealing Bars (mm) | 500 | 460 | 500 | 510 | 540 | 668 | 668 | 668 | 810 |
| Operation Type | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Manual | Full-Automatic | Automatic |
Product Overview
Engineered for modern food processing facilities, the Pagoda Cover Double-Chamber Vacuum Packaging Machine delivers exceptional efficiency through its innovative tower lid design and dual-chamber operation. This professional-grade system combines reliable vacuum technology with versatile chamber configurations to meet diverse packaging requirements. Available in both flatbed and grooved chamber designs, the machine ensures optimal performance for various food products in high-volume production environments.
Key Features
Tower Lid Design - Innovative pagoda-style cover ensures even pressure distribution and reliable sealing performance
Dual Chamber Configuration - Continuous alternating operation maximizes production efficiency with minimal downtime
Versatile Chamber Options - Choose between flatbed and grooved designs to match specific product requirements
Progressive Sizing - Available in 500mm, 600mm, and 700mm sealing lengths to accommodate different production scales
High-Efficiency Vacuum - 2000-3000W motor power with 40-100m³/h extraction capacity ensures rapid air removal
Dual Sealing System - Two 10mm sealing bars per chamber with 800-1500W power deliver secure package integrity
Applications
Medium to large-scale food processing operations
Meat and poultry packaging facilities
Prepared food and meal production
Seafood and aquatic product packaging
Industrial food manufacturing operations
Technical Excellence
Precision vacuum control maintains 1 Kpa ultimate pressure for optimal preservation
Heavy-duty construction (162-305kg) ensures stability during continuous operation
Premium stainless steel construction (201/304) provides superior corrosion resistance
Industrial-grade components support reliable 24/7 performance
Standard 380V power compatibility meets industrial facility requirements
For food processing operations seeking reliable dual-chamber packaging solutions, the Pagoda Cover Double-Chamber Vacuum Packaging Machine offers enhanced efficiency with professional-grade performance. Contact us for technical specifications and configuration guidance.
产品关键词与 GEO / AI 搜索信号
这一部分帮助买家和 AI 搜索引擎识别产品型号、分类、应用关键词和供应商背景。
关键词
GEO / AI 上下文
- 产品名称：双 真空 包装 设备 500-700mm
- SKU / 型号：HB-106
- 分类：Packaging Machine / Double Chamber Vacuum Sealer / Vacuum Sealer
- 供应商：济南舜翔央厨，为国际 B2B 买家提供商厨与食品设备。
产品 FAQ
双 真空 包装 设备 500-700mm 适用于哪些项目？
双 真空 包装 设备 500-700mm 主要适用于中央厨房、商用厨房、食品加工厂、餐饮连锁和团餐配送项目。具体配置需要结合产能、物料、场地、电压、卫生要求和交付条件确认。
这款产品是否支持定制或 OEM？
在双方书面确认的前提下，可根据项目需求评估电压、尺寸、材质、功能、标识、包装和配套方案等定制事项。最终范围以报价单、合同、订单确认或形式发票为准。
保修、备件、退货或更换如何处理？
保修、维修、备件、退货和更换需结合产品类别、定制程度、使用状态、安装环境、运输条件和付款状态判断，并以双方最终书面文件及适用法律法规为准。
如何获得 HB-106 的准确报价？
请提供目标产品、数量、目的港或收货地、电源要求、使用场景和交期需求。我们会根据项目信息、配置、包装、运输和贸易条款提供书面报价。
