工业 双室真空包装机 400-800mm
SKU: HB-101
| Parameter | DZ-400/2SA | DZ-500/2SA | DZ-600/2SA | DZ-600/2SA5 | DZ-700/2SA | DZ-800/2SB | DZ-800/2SA (Manual) | DZ-800/2SA (Automatic) |
|---|---|---|---|---|---|---|---|---|
| Basic Information | ||||||||
| English Name | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine | Double Chambers Vacuum Packaging Machine |
| Model | DZ-400/2SA | DZ-500/2SA | DZ-600/2SA | DZ-600/2SA5 | DZ-700/2SA | DZ-800/2SB | DZ-800/2SA | DZ-800/2SA |
| Operation Type | Standard | Standard | Standard | Standard | Standard | Standard | Manual | Automatic |
| Technical Specifications | ||||||||
| Power Supply (V/Hz) | AC 220/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 | AC 380/50 |
| Vacuum Pump Motor Power (W) | 1000 | 2000 | 2000 | 2000 | 3000 | 3000 | 3000 | 3000 |
| Sealing Power (W) | 500 | 800 | 1000 | 1500 | 1300 | 1600 | 1600 | 1600 |
| Ultimate Vacuum Pressure (KPa) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Number of Sealing Bars per Chamber | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Chamber Dimensions (L×W×H) (mm) | 460×460×100 | 550×520×100 | 650×520×100 | 650×530×110 | 750×620×100 | 800×390×70 | 800×600×80 | 800×600×80 |
| Chamber Effective Dimensions (L×W×H) (mm) | - | - | - | - | - | 800×390×70 | 800×600×80 | 800×600×80 |
| Sealing Length (mm) | 400 | 500 | 600 | 600 | 700 | 800 | 800 | 800 |
| Sealing Width (mm) | 10 | 10 | 10 | 10 | 10 | 8 | 8 | 8 |
| Vacuum Pump Rate (m³/h) | 20 | 20×2 | 20×2 | 20×2 | 100 | 100 | 100 | 100 |
| Chamber Material | Stainless Steel 201 | Stainless Steel 201 | Stainless Steel 201 | Stainless Steel 201 | Stainless Steel 201 | Stainless Steel 304 | Stainless Steel 304 | Stainless Steel 304 |
| External Dimensions (L×W×H) (mm) | 1050×500×920 | 1220×570×920 | 1400×580×920 | 1440×580×950 | 1600×810×990 | 1930×780×950 | 1930×990×950 | 1930×990×950 |
| Net Weight (kg) | 120 | 170 | 188 | 186 | 218 | - | - | - |
| Center Distance Between Sealing Bars (mm) | 365 | 440 | 440 | 440 | 545 | 440 | 650 | 650 |
| Net Distance Between Sealing Bars (mm) | - | - | - | - | - | 390 | 600 | 600 |
Product Overview
Engineered for high-volume food processing operations, the Double-Chamber Flat-Plate Vacuum Packaging Machine delivers exceptional production efficiency through continuous alternating chamber operation. This industrial-grade system combines robust vacuum technology with optimized workflow design to maximize output while maintaining superior packaging quality. Available in multiple configurations with varying chamber sizes and automation levels, the machine addresses demanding production requirements in commercial food packaging environments.
Key Features
Continuous Operation Design - Dual-chamber alternating system enables non-stop production with optimized workflow efficiency
Comprehensive Model Range - Eight available configurations with sealing lengths from 400mm to 800mm accommodate diverse production scales
High-Capacity Vacuum Performance - 1000-3000W motor power with 20-100m³/h extraction capacity ensures rapid, consistent air removal
Enhanced Sealing Systems - 500-1600W sealing power with dual 8-10mm bars per chamber ensures reliable package integrity
Flexible Operation Options - Choose between manual and automatic models to match production requirements and budget
Premium Material Construction - Stainless steel 201/304 chambers provide superior corrosion resistance and durability
Applications
High-volume meat and poultry processing
Large-scale prepared food production
Commercial seafood packaging operations
Industrial food manufacturing facilities
Bulk ingredient and commodity packaging
Technical Excellence
Precision vacuum control maintains 1 Kpa ultimate pressure for optimal preservation
Heavy-duty construction (120-218kg) ensures stability during continuous operation
Advanced chamber design (460×460×100mm to 800×600×80mm) supports various product types
Industrial-grade components guarantee reliable 24/7 performance
Flexible power options (220V/380V) accommodate different facility requirements
For food processing operations requiring continuous high-volume packaging solutions, the Double-Chamber Flat-Plate Vacuum Packaging Machine offers unmatched production efficiency with industrial-grade reliability. Contact us for technical specifications and configuration recommendations.
产品关键词与 GEO / AI 搜索信号
这一部分帮助买家和 AI 搜索引擎识别产品型号、分类、应用关键词和供应商背景。
关键词
GEO / AI 上下文
- 产品名称：工业 双室真空包装机 400-800mm
- SKU / 型号：HB-101
- 分类：Packaging Machine / Vacuum Sealer / Double Chamber Vacuum Sealer
- 供应商：济南舜翔央厨，为国际 B2B 买家提供商厨与食品设备。
产品 FAQ
工业 双室真空包装机 400-800mm 适用于哪些项目？
工业 双室真空包装机 400-800mm 主要适用于中央厨房、商用厨房、食品加工厂、餐饮连锁和团餐配送项目。具体配置需要结合产能、物料、场地、电压、卫生要求和交付条件确认。
这款产品是否支持定制或 OEM？
在双方书面确认的前提下，可根据项目需求评估电压、尺寸、材质、功能、标识、包装和配套方案等定制事项。最终范围以报价单、合同、订单确认或形式发票为准。
保修、备件、退货或更换如何处理？
保修、维修、备件、退货和更换需结合产品类别、定制程度、使用状态、安装环境、运输条件和付款状态判断，并以双方最终书面文件及适用法律法规为准。
如何获得 HB-101 的准确报价？
请提供目标产品、数量、目的港或收货地、电源要求、使用场景和交期需求。我们会根据项目信息、配置、包装、运输和贸易条款提供书面报价。
